Silicone pulverizer Silicone rubber pulverizer Elastomer silicone shredder
1.Viscosity: Silica gel has adhesion, and there will be a sticky knife not materialization during the crushing process;
2.Material: silicone characteristics are soft and tough, not easy to break;
Gu'an mechanical crusher designs the most reasonable knife shaft speed for the particularity of elastomer silicone, etc.; And with special material tools, excellent cutting force; Cooling water circulation is also added to the fuselage box to keep the fuselage running at low temperatures, reduce the adhesion of the material, make the unloading smoother, and improve the crushing effect.
When the model is applied to the crushing of silicone products, it can be used to crush hard PC, POM, PA and other thin products at the same time. For example, the crushing, frame and strap of the swimming goggle product are very soft silicone or TPR, TPU materials, but the lenses are relatively hard and wear-resistant PC materials, both of which can be handled very well with this crusher.
Because the tool material of this model is high-speed steel, the hardness is between 58-61, the soft glue has very excellent cutting performance, with a reasonable shaft speed and the treated unloading screen, the crushing effect for soft glue such as silicone, rubber, elastomer, etc. is very good, the cutting surface is smooth, the speed is fast and efficient, it can work continuously for a long time, non-sticking, and the unloading is smooth.
At the same time, because the wear resistance of this tool is very good, the grinding of the hard glue is also very efficient, and the number of sharpening times can be reduced by 50% for a long time. It should be noted that this model is not suitable for heavy and large block crushing, only suitable for thin products.
Gu'an silicone shredder designed this silicone special crusher for the above characteristics, which solved the above problems:
1. Tool: adopt more than three times the ordinary material wear-resistant tool;
2. Angle: using scissor cutting method, cutting silica gel at one time, not giving it a second cutting opportunity, to avoid repeated friction affecting its characteristics;
3. Speed: After many years of experience in the production of crushers, Gu An calculated a reasonable speed, with the silicone crusher, play a value;
4. Cooling: In the process of crushing, if you are worried that the shredder will run for a long time, resulting in insufficient heat dissipation time of the machine and heating up, you can install water-cooled or air-cooled devices according to the rubber materials of different temperature-resistant properties.
Suzhou silicone crusher silicone rubber crusher elastomer silicone crusher features:
1▪ Double layer into the hopper, filled with sound insulation materials, effectively reduce the working noise;
2▪ The crushing chamber is fully polished and grinded, and the overall processing is carried out after the welding of the thickened steel plate, with good precision;
3▪ The knife holder adopts wire cutting processing to ensure accuracy, perfect coordination with the central axis, and clean assembly;
4▪ The central shaft and the knife holder are hydraulically assembled and formed, without any solder joints, without hiding materials, which is conducive to cleaning and avoiding deformation caused by sintering;
5▪ The top knife block and the knife holder are cut from the same thick steel plate, which is beautiful and generous, and will not shift or fall off over the years, while avoiding welding slag storage;
6▪ The claw knife type adopts symmetrical step arrangement to disperse the impact load, so that the large size of the block crushing is more labor-saving, and each knife can be rotated 180 degrees for secondary use, reducing the number of sharpening times;
7▪ The tool adopts imported alloy steel, according to the characteristics of different materials, SKD-11 or SKH2 is selected, and the perfect material ensures excellent quality;
8▪ SMD-150 or more, equipped with shredding chamber cooling water device, which can effectively reduce the working temperature of the shredding chamber and avoid material agglomeration;
9▪ Protection function: motor overload protection, limit switch protection, etc
Q1: Why does my shredder stick to the knife and clump when crushing these materials?
A: Because your material is hot melt, it will melt at high temperatures and appear adhesion.
Q2: Ordinary hard plastics will be hot when crushed, how can they not stick?
Answer: Ordinary plastics have high hardness, are relatively brittle, and can be broken through the impact, extrusion and cutting of the tool.
Moreover, ordinary materials are not easy to melt in a hot environment, so there will be no sticking knife phenomenon.
Q3: When the shredder is working, how high will the temperature be?
A: When the pulverizer crushes the material, after 30 minutes of continuous work, the temperature of the material in the crushing chamber can rise to 60-90 ° C
(Depending on the characteristics of the material, there will be differences)
